Detail

2K⁺ Pan-and-Tilt Lens

Rotational view for the whole picture

2K⁺ Wide-Angle Lens

Fixed view for the main area

Dual lenses. More than double vision.

The C7 Dual helps you understand your spacious interior with far less blind spots, while keeping a continuous watch on the key activity area.

PT lens

Fixed lens

Step 1

The bottom lens detects a moving person

Step 2

The top lens rotates in 360° and follows the moving person

C7 Dual-Lens Pan & Tilt Wi-Fi Camera

AI-Powered Human Shape Detection

C7 Dual-Lens Pan & Tilt Wi-Fi Camera
C7 Dual-Lens Pan & Tilt Wi-Fi Camera

AI-Powered Pet Detection

C7 Dual-Lens Pan & Tilt Wi-Fi Camera
C7 Dual-Lens Pan & Tilt Wi-Fi Camera

Loud Noise Detection

C7 Dual-Lens Pan & Tilt Wi-Fi Camera
C7 Dual
Clear and complete coverage with dual lenses
C7 Dual-Lens Pan & Tilt Wi-Fi Camera
Specifications
Specifications
ModelCS-C7-R100-8G44WF
Camera
ResolutionDual 2K+ Resolution
Image Sensor1/3" Progressive Scan CMOS
Shutter SpeedSelf-adaptive shutter
Fixed Lens2.8mm@F1.6 , view angle: 108°(Diagonal), 92° (Horizontal), 50°(Vertical)
PT Lens6mm@F1.6 , view angle: 60°(Diagonal), 51° (Horizontal), 28°(Vertical)
Lens MountM12
Day & NightIR-cut filter with auto-switching
DNR3D DNR
WDRDigital WDR
Compression
Video CompressionH.264/H.265
Video Bit RateAdaptive bit rate.
Network
Smart AlarmMotion Detection, Human Shape Detection, Pet Detection, Patrol Mode Detection
Wi-Fi PairingAP Pairing / Bluetooth Pairing
ProtocolEZVIZ cloud proprietary protocol
Interface ProtocolEZVIZ cloud proprietary protocol
Max. Resolution2560 × 1440
Frame RateSelf-Adaptive during network transmission
Interface
StorageMicro SD card slot (Max. 512G)
PowerTYPE-C
Wi-Fi
StandardIEEE802.11b, 802.11g, 802.11n,802.11ac 802.11ax
Frequency Range2.4GHz: 2.4 GHz ~ 2.4835 GHz 5GHz: 5.150GHz~5.250GHz
Channel Bandwidth2.4GHz Supports 20MHz 5GHz Supports 80MHz
SecurityWPA-PSK, WPA2-PSK, WPA3-Personal
Transmission Rate2.4GHz Max. Rate Support: 11b_11M，11g_54M, 11n_MCS7_20M，11ax_MCS11_20M 5.15-5.25GHz Max. Rate Support: 11a_54M, 11n_MCS7_20-40M，11ac_MCS9_20-40-80M, 11ax_MCS11_20-40-80M
Output Power(EIRP)20 dBm
Antenna Gain2.56dBi@2.48GHz，3.18dBi@5.22GHz
General
Operating Conditions-20°C to 50°C ( -4 °F to 122 °F ) Humidity 95% or less (non-condensing)
Power ConsumptionMax. 8W
Power SupplyDC 5V/2A
IR RangeMAX. 10 meters (33 ft)
Dimensions100 × 100 × 98 mm (3.94 × 3.94 × 3.86 inch)
Package Dimensions117 × 117 × 165 mm (4.61 × 4.61 × 6.5 inch)
Net Weight310 g
Bare Weight610 g
In the box
In the box- Camera (x1)
- Power Adapter (x1)
- Power Cable (x1)
- Drill Template (x1)
- Mounting Plate (x1)
- Screw Kit (x1)
- Regulatory Information (x1)
- Quick Start Guide (x1)
Certifications
CertificationsCE / UKCA / WEEE / RoHS / REACH / UL
