    TY1 Pro 3K

    Detail
    TY1 Pro

    3K

    Type-C

    Pan & Tilt Smart Home Camera

    TY1 Pro

    TY1 Pro Pan & Tilt Smart Home Camera

    3K

    Type-C

    Pan & Tilt Smart Home Camera

    TY1 Pro Pan & Tilt Smart Home Camera

    Smart color night vision up to 5 meters away

    TY1 Pro Pan & Tilt Smart Home Camera

    Nighttime imaging up to 10 meters away

    TY1 Pro Pan & Tilt Smart Home Camera

    Less overexposure

    TY1 Pro Pan & Tilt Smart Home Camera

    Clearer details

    TY1 Pro Pan & Tilt Smart Home Camera

    Smart color night vision up to 5 meters away

    TY1 Pro Pan & Tilt Smart Home Camera

    Nighttime imaging up to 10 meters away

    TY1 Pro Pan & Tilt Smart Home Camera

    Less overexposure

    TY1 Pro Pan & Tilt Smart Home Camera

    Clearer details

    Enhanced viewing pleasure with smaller video files

    Compared to the prevailing H.264 video compression technology, H.265 creates a more fluid viewing experience. Meanwhile, you won’t have to worry about large video files taking up too much of your storage space – H.265 technology reduces their sizes by up to 50%³.

    50%

    TY1 Pro Pan & Tilt Smart Home Camera

    Video Storage Space

    50%

    TY1 Pro Pan & Tilt Smart Home Camera

    Required Bandwidth

    Enhanced viewing pleasure with smaller video files

    Compared to the prevailing H.264 video compression technology, H.265 creates a more fluid viewing experience. Meanwhile, you won’t have to worry about large video files taking up too much of your storage space – H.265 technology reduces their sizes by up to 50%³.

    50%TY1 Pro Pan & Tilt Smart Home CameraVideo Storage Space
    50%TY1 Pro Pan & Tilt Smart Home CameraRequired Bandwidth

    EZVIZ has been awarded by DNV forinformation security (ISO/IEC 27001:2013),personal data protection (ISO/IEC 27701:2019),cloud security (CSA STAR) and more.

    TY1 Pro 3K
    Sharper vision, smarter security
    TY1 Pro Pan & Tilt Smart Home Camera
    Specifications
    Specifications
    Model CS-TY1-R105-1J5WF
    Camera
    Image Sensor 1/2.7" Progressive Scan CMOS
    Shutter Speed Self-adaptive shutter
    Lens 4mm @ F1.6, viewing angle: 87° (Horizontal), 53° (Vertical), 104° (Diagonal)
    Lens Mount M12
    Day & Night IR-cut filter with auto switch
    DNR 3D DNR
    WDR Digital WDR
    Compression
    Video Compression H.264/H.265
    Video Bit Rate Adaptive bit rate.
    Max. Resolution 2880 × 1620
    Frame Rate Self-Adaptive during network transmission
    Network
    Smart Alarm Motion Detection, Human Shape Detection, Loud Noise Detection, Patrol Mode Detection
    Wi-Fi Pairing AP paring
    Protocol EZVIZ cloud proprietary protocol
    Interface Protocol EZVIZ cloud proprietary protocol
    Interface
    Storage Micro SD card slot (Max. 512G)
    Power TYPE-C
    Wired Network RJ45 X 1 (10M/100M self-adaptive Ethernet port)
    Wi-Fi
    Standard IEEE802.11a, 802.11b, 802.11g, 802.11n
    Frequency Range 2.4G: 2400~2483.5MHz 5G: 5150MHz-5250MHz
    Channel Bandwidth Supports 20MHz
    Security WPA/WPA2, WPA-PSK/WPA2-PSK
    Transmission Rate 11b 11Mbps, 11g 54Mbps, 11nHT20 MCS7, 11a 54Mbps, 11nHT20 MCS7
    Output Power(EIRP) 19 dBm
    Antenna Gain 1.9 dBi
    General
    Operating Conditions -10°C to 45°C (14°F to 113 °F ), Humidity 95% or less (non-condensing)
    Power Supply DC 5V/2A
    Power Consumption MAX. 8W
    IR Range MAX. 10 meters(32.81ft)
    Dimensions 88mm x 88.2 mm x 119mm (3.46” x 3.47” x 4.69”)
    Packaging Dimensions 103mm x 103mm x 168mm (4.06” x 4.06” x 6.61”)
    Bare Weight 213 g (0.47 lb)
    In the box
    In the box - TY1 Pro 3K Camera
    - Power Adapter
    - Power Cable
    - Drill Template
    - Mounting Plate
    - EZVIZ Screw Kit
    - Regulatory Information
    - Quick Start Guide
    Certifications
    Certifications CE / UL / WEEE / REACH / RoHS
