TY1 Pro 4K

Detail

TY1 Pro

Type-C

TY1 Pro

Type-C

Unveiling TY1 Pro 4K, the newest innovation to experience next-level home security. It secures your home with sophisticated 4K lens. Swiftly responding to movements and sounds, this smart camera smartly rotates with no corner of your space unnoticed. What’s more, a handy call button keeps your family in close touch with you.

EZVIZ CP1 Pro Pan & Tilt Smart Home Camera

360° Panoramic View

Smart Color Night Vision

Smart Human Shape Detection

Loud Noise Detection

Two-Way Calling with Touch Button

Sleep Mode for Privacy Protection

H.265 Video Compression

Supports Dual-Band Wi-Fi 6 (2.4 / 5 GHz)¹

Supports MicroSD Card (Up to 512 GB) & EZVIZ CloudPlay Storage²

With the TY1 Pro, there's no more frustration due to a restricted view or a blurry footage. It sees every corner of your interior space in stunning and vivid 4K ultra clarity, just as if you were at home. You can easily control the lens to pan and tilt smoothly, and zoom to see details that matter most to you.

55°

Vertical Rotation

340°

Vertical Rotation

55°

Vertical Rotation

The TY1 Pro pans and tilts automatically to eliminate blind spots with its unique patrol mode. You can even customize patrol pattern in accordance with your very special home, leaving no corner uncovered.

Overall Patrol

Customize Patrol

Pan horizontally

Follow the order of pre-set points (Up to 4 points)

A lot of activities go on inside your home. Don't want to get alerted repeatedly when your curtains flutter in the wind? The TY1 Pro is smart enough to identify human activities in particular. You can choose to get alerted only when somebody is detected on camera.

The camera can automatically zoom in up to 4 times to follow a moving person so you see details and get the whole picture at the same time. You can always enable the AI option to detect and track specifically human movements.

It’s important to know if you’re needed by your loved ones. The camera alerts you if the noise level suddenly changes – whether your baby cries or a siren blares. In addition, they can contact you from the camera’s side by simply tapping the call button - one of the easiest way to make a video call.

Loud Noise Detection

Touch Call Button

Loud Noise Detection

Touch Call Button

Compared to the prevailing H.264 video compression technology, H.265 creates a more fluid viewing experience. Meanwhile, you won’t have to worry about large video files taking up too much of your storage space – H.265 technology reduces their sizes by up to 50%³.

50%

Video Storage Space

50%

Required Bandwidth

50%

Video Storage Space

50%

Required Bandwidth

We put security as the primary goal of every product and system that we build. We have also developed various privacy features and flexible settings that you can use at any time to feel even safer.

You will need to choose the Wi-Fi frequency band during the device setup process. Once the choice is made, you will not be able to change it to another frequency band.
Local storage cards must be purchased separately. Cloud storage service is only available in certain markets. Please verify availability before making a purchase.
Data from EZVIZ Lab’s test results under standard conditions. The video compression efficiency will vary with the frequency and complexity of the activity captured, and other environmental factors.

TY1 Pro 4K

Sharper vision, smarter security

Specifications

Specifications
Model	CS-TY1-R105-8G8WF
Camera
Image Sensor	F1.6@1/2.7" Progressive Scan CMOS
Shutter Speed	Self-adaptive shutter
Lens	4mm @ F1.6, view angle: 106°(Diagonal), 90° (Horizontal), 48°(Vertical)
Lens Mount	M12
Day & Night	IR-cut filter with auto-switching
DNR	3D DNR
WDR	Digital WDR
Compression
Video Compression	H.264/H.265
Video Bit Rate	Adaptive bit rate
Max. Resolution	4K (3840 × 2160)
Frame Rate	Self-adaptive during network transmission
Network
Smart Alarm	Motion detection AI-powered human shape detection Loud noise detection Patrol mode detection
Wi-Fi Pairing	AP paring
Protocol	EZVIZ cloud proprietary protocol
Interface Protocol	EZVIZ cloud proprietary protocol
Interface
Storage	Supports microSD card (max. 512 GB)
Power	Type-C
Wired Network	RJ45 × 1 (10 M / 100 M self-adaptive Ethernet port)
Wi-Fi
Standard	IEEE802.11a, 802.11b, 802.11g, 802.11n
Frequency Range	2.4G: 2400~2483.5MH 5G: 5150MHz-5250MHz
Channel Bandwidth	Supports 20MHz
Security	WPA/WPA2, WPA-PSK/WPA2-PSK
Transmission Rate	11b 11Mbps, 11g 54Mbps, 11nHT20 MCS7, 11a 54Mbps, 11nHT20 MCS7
Output Power(EIRP)	19 dBm
Antenna Gain	1.9 dBi
General
Operating Conditions	-10°C to 45°C (14°F to 113 °F Humidity 95% or less (non-condensing)
Power Supply	DC 5V/2A
Power Consumption	MAX. 8W
IR Range	MAX. 10 meters(32.81ft)
Dimensions	88 × 88.2 × 119 mm (3.46 × 3.47 × 4.69 inch)
Packaging Dimensions	103 × 103 × 168 mm (4.06 × 4.06 × 6.61 inch)
Net Weight	213 g (0.47 lb)
In the box
In the box	- TY1 Pro 4K Camera
	- Power Adapter
	- Power Cable
	- Drill Template
	- Mounting Plate
	- Screw Kit
	- Regulatory Information × 2
	- Quick Start Guide
Certifications
Certifications	CE / UL / WEEE / REACH / RoHS
